ROD-25 GRIFFON
Organic Fertilizer Spreader ROD-25 GRIFON
Carrying capacity, kg 22 300
Body volume, m³ 20-30
Tractor power, hp 300-350
Consultation
Characteristic:
| Technical characteristics: | |
| Volume,m3
Volume with patches,m3 |
20 30 |
| Payload capacity, kg | 22 300 |
| Own weight, kg | 13 200 |
| Management | ISOBUS |
| Semitrailer dimensions, LxWxH, m | 10,8 × 2,91 × 3,85 |
| Wheels | 600/55 R26,5 |
| Required tractor power hp | 300-350 |
| Working width, m | 12 |
Kobzarenko Plant LLC has presented the innovative spreader for liquid organic fertilizers ROD-25 “GRIFON”. This new product was specifically developed for agricultural holdings and large-scale farms that use precision farming technologies.
- Payload capacity: 22.3 t (20 m³ body volume – up to 30 m³ with extensions)
- Tyres: 600/55 R26.5
- For tractors: 300–350 hp
ADVANTAGES OF THE ROD-25:
- Tridem axle – lower soil compaction
- Reinforced belt drive gearboxes compared to competitors
- Spreading limiter for field edge application
- Wooden protection beam for loading safety
- Volume – up to 30 m³
- Italian components (Berma and Grazioli gearboxes)
- ADR axles and suspension
- GPS system
WEIGHING SYSTEM AS THE BASIS OF ACCURACY
For organic fertilizers, this is critical because manure, compost, or digestate often have varying density and moisture content. The spreader uses an algorithm from DigiDevice, namely SPEED CONTROL, which is linked to the tractor’s speed and the spreading window width. As a result, the actual application rate in t/ha becomes closer to the set target, even if the material is heterogeneous.
